**Topic: Custom Widgets and Components** In this example, we'll create a custom "Slider With Preview" widget using PyQt6. This widget will have a slider that displays a preview of the current value, which can be especially useful for media players or other applications that require users to adjust a value within a specific range. **slider_with_preview.py** ```python import sys from PyQt6.QtCore import Qt, QObject, pyqtSlot from PyQt6.QtGui import QPainter, QBrush, QColor from PyQt6.QtWidgets import QApplication, QWidget, QSlider, QHBoxLayout class SliderWithPreview(QSlider): def __init__(self, parent=None): super().__init__(parent) self._preview_value = self.minimum() self._preview_rect = None def paintEvent(self, event): super().paintEvent(event) self._paint_preview(event) def _paint_preview(self, event): painter = QPainter(self) painter.setRenderHint(painter.Antialiasing) preview_x = self._preview_rect.x() if self._preview_rect else 0 preview_y = self._preview_rect.y() if self._preview_rect else 0 preview_w = self._preview_rect.width() if self._preview_rect else 0 preview_h = self._preview_rect.height() if self._preview_rect else 0 if preview_w == 0: preview_w = 20 preview_h = 20 preview_x = self.width() - preview_w - 5 preview_y = 5 painter.setPen(QColor('black')) painter.setBrush(QColor('lightblue')) painter.drawRoundedRect(preview_x, preview_y, preview_w, preview_h, 5, 5) painter.setPen(QColor('black')) painter.drawText(preview_x + 5, preview_y + 15, f"{self._preview_value}") def resizeEvent(self, event): super().resizeEvent(event) self._update_preview_rect() def _update_preview_rect(self): slider_height = self.height() preview_w = 20 preview_h = 20 preview_x = self.width() - preview_w - 5 preview_y = (slider_height - preview_h) // 2 self._preview_rect = (preview_x, preview_y, preview_w, preview_h) def _calculate_preview_value(self): range_value = self.maximum() - self.minimum() slider_value = self.value() - self.minimum() preview_value = self.minimum() + int((slider_value / range_value) * range_value) return preview_value @pyqtSlot(int) def on_slider_value_changed(self, value): self._preview_value = self._calculate_preview_value() self.update() class CustomWidget(QWidget): def __init__(self, parent=None): super().__init__(parent) self.slider = SliderWithPreview() self.slider.setRange(0, 100) layout = QHBoxLayout() layout.addWidget(self.slider) self.setLayout(layout) self.slider.valueChanged.connect(self.slider.on_slider_value_changed) if __name__ == "__main__": app = QApplication(sys.argv) widget = CustomWidget() widget.show() sys.exit(app.exec()) ``` **Explanation** We create a custom `SliderWithPreview` widget by subclassing `QSlider`. This custom widget will display a preview of the current value next to the slider. **_paint_preview method** This method is responsible for painting the preview. It creates a `QPainter` object, sets its render hint to `Antialiasing` for a smoother preview, and then draws a lightblue rounded rectangle with the current value. **resizeEvent and _update_preview_rect methods** When the slider's size is updated, we update the position and size of the preview rectangle. **on_slider_value_changed slot** When the slider's value changes, we calculate the new preview value and update the widget to display the new preview. **CustomWidget** We create a `CustomWidget` that creates an instance of the `SliderWithPreview` widget, adds a layout, and sets the connections between the slider's `valueChanged` signal and the `on_slider_value_changed` slot. **Output** When you run this code, you should see a custom slider widget with a preview of the current value. **Design Considerations** To enhance app design and development, you can further customize this widget by adding additional features, such as: 1. Customizable fonts and colors. 2. Rounded rectangle edges or other shapes for the preview. 3. The ability to set a specific width or height for the preview. 4. Additional preview layouts for horizontal or vertical sliders. These design considerations will help create a more modern and user-friendly widget that enhances the overall app design and user experience.

import sys
from PyQt6.QtCore import Qt, QObject, pyqtSlot
from PyQt6.QtGui import QPainter, QBrush, QColor
from PyQt6.QtWidgets import QApplication, QWidget, QSlider, QHBoxLayout

class SliderWithPreview(QSlider):
    def __init__(self, parent=None):
        super().__init__(parent)
        self._preview_value = self.minimum()
        self._preview_rect = None

    def paintEvent(self, event):
        super().paintEvent(event)
        self._paint_preview(event)

    def _paint_preview(self, event):
        painter = QPainter(self)
        painter.setRenderHint(painter.Antialiasing)
        preview_x = self._preview_rect.x() if self._preview_rect else 0
        preview_y = self._preview_rect.y() if self._preview_rect else 0
        preview_w = self._preview_rect.width() if self._preview_rect else 0
        preview_h = self._preview_rect.height() if self._preview_rect else 0

        if preview_w == 0:
            preview_w = 20
            preview_h = 20
            preview_x = self.width() - preview_w - 5
            preview_y = 5

        painter.setPen(QColor('black'))
        painter.setBrush(QColor('lightblue'))
        painter.drawRoundedRect(preview_x, preview_y, preview_w, preview_h, 5, 5)

        painter.setPen(QColor('black'))
        painter.drawText(preview_x + 5, preview_y + 15, f"{self._preview_value}")

    def resizeEvent(self, event):
        super().resizeEvent(event)
        self._update_preview_rect()

    def _update_preview_rect(self):
        slider_height = self.height()
        preview_w = 20
        preview_h = 20
        preview_x = self.width() - preview_w - 5
        preview_y = (slider_height - preview_h) // 2
        self._preview_rect = (preview_x, preview_y, preview_w, preview_h)

    def _calculate_preview_value(self):
        range_value = self.maximum() - self.minimum()
        slider_value = self.value() - self.minimum()
        preview_value = self.minimum() + int((slider_value / range_value) * range_value)
        return preview_value

    @pyqtSlot(int)
    def on_slider_value_changed(self, value):
        self._preview_value = self._calculate_preview_value()
        self.update()

class CustomWidget(QWidget):
    def __init__(self, parent=None):
        super().__init__(parent)
        self.slider = SliderWithPreview()
        self.slider.setRange(0, 100)

        layout = QHBoxLayout()
        layout.addWidget(self.slider)
        self.setLayout(layout)

        self.slider.valueChanged.connect(self.slider.on_slider_value_changed)

if __name__ == "__main__":
    app = QApplication(sys.argv)
    widget = CustomWidget()
    widget.show()
    sys.exit(app.exec())
